PLANET GS-5220-16S8C 24x 100/1000 SFP @ 8x 10/100/1000BaseT, L3

PLANET GS-5220-16S8C on hallittava L3-tason Ethernet-kytkin.
19" räkkiasennettavan kytkin on varustettu 24x 100/1000 SFP
modulipaikalla sekä 8x 10/100/1000Base-T jaetuilla
kupariporteilla.

Tekniset tiedot:

Physical Port
• 24x 100/1000Base-X mini-GBIC/SFP slots
• 8-port 10/100/1000Base-T Gigabit Ethernet RJ-45, shared
with Port-1 to Port-8
• RJ45 to RS-232 DB9 console interface for basic management
and setup

Layer 2 Features
• Prevents packet loss with back pressure (half-duplex) and
• IEEE 802.3x pause frame flow control (full-duplex)
• High performance of Store-and-Forward architecture and
runt/CRC filtering eliminates erroneous packets to optimize
the network bandwidth
• Storm Control support
- Broadcast / Unicast / Unknown Unicast
• Supports VLAN
- IEEE 802.1Q tagged VLAN
- Up to 255 VLANs groups, out of 4095 VLAN IDs
- Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
- Private VLAN Edge (PVE)
- Protocol-based VLAN
- MAC-based VLAN
- IP Subnet-based VLAN
- Voice VLAN
• Supports Spanning Tree Protocol
- STP, IEEE 802.1D Spanning Tree Protocol
- RSTP, IEEE 802.1w Rapid Spanning Tree Protocol
- MSTP, IEEE 802.1s Multiple Spanning Tree Protocol,
spanning tree by VLAN
- BPDU Guard
• Supports Link Aggregation
- 802.3ad Link Aggregation Control Protocol (LACP)
- Cisco ether-channel (Static Trunk)
- Maximum 12 trunk groups, up to 8 ports per trunk group
- Up to 16Gbps bandwidth (full duplex mode)
• Provides Port Mirror (many-to-1)
• Loop protection to avoid broadcast loops
Layer 3 IP Routing Features
• Supports maximum 128 static routes and route summarization

Quality of Service
• Ingress Shaper and Egress Rate Limit per port bandwidth
control
• 8 priority queues on all switch ports
• Traffic classification
- IEEE 802.1p CoS
- TOS / DSCP / IP Precedence of IPv4/IPv6 packets
- IP TCP/UDP port number
- Typical network application
• Strict priority and Weighted Round Robin (WRR) CoS
policies
• Traffic-policing policies on the switch port
• DSCP remarking

Multicast
• Supports IGMP Snooping v1, v2 and v3
• Supports MLD Snooping v1 and v2
• Querier mode support
• IGMP Snooping port filtering
• MLD Snooping port filtering
• MVR (Multicast VLAN Registration)

Security
• IEEE 802.1X Authentication with Guest VLAN
• Built-in RADIUS client to cooperate with the RADIUS
servers
• RADIUS / TACACS+ users access authentication
• IP-based Access Control List (ACL)
• MAC-based Access Control List (ACL)
• Source MAC / IP address binding
• DHCP Snooping to filter distrusted DHCP messages
• Dynamic ARP Inspection discards ARP packets with invalid
MAC
• address to IP address binding
• IP Source Guard prevents IP spoofing attacks
• IP address access management to prevent unauthorized
intruder

Management
• Switch Management Interfaces
- Console / Telnet Command Line Interface
- Web switch management
- SNMP v1, v2c, and v3 switch management
- SSH / SSL secure access
• Four RMON groups (history, statistics, alarms and events)
• IPv6 Address / NTP management
• Built-in Trivial File Transfer Protocol (TFTP) client
• BOOTP and DHCP for IP address assignment
• Firmware upload / download via HTTP / TFTP
• DHCP Relay and Option 82
• User Privilege levels control
• NTP (Network Time Protocol)
• Link Layer Discovery Protocol (LLDP)
• SFP-DDM (Digital Diagnostic Monitor)
• Cable Diagnostic technology provides the mechanism to
detect and report potential cabling issues for TP ports
• ICMPv6 / ICMPv4 Remote Ping
• Reset button for system reboot or reset to factory default
• SMTP / Syslog / SNMP Trap remote alarm
• System Log
• PLANET Smart Discovery Utility for deploy management
